Tk.211,000.00 (MSRP)
WCI-HEXACARE-48Z |
|
| Air Conditioner Type | Cassette Air Conditioner |
| Function | Cooling |
| Cooling Capacity | 48000 BTU/Hr |
| 14068 Watts | |
| 4 Ton | |
| Compressor | Twin Rotary (Variable Speed) |
| Refrigerant | R-410a |
| Apply for Kisti | Exchange Now |
WCI-HEXACARE-48Z |
|
| Air Conditioner Type | Cassette Air Conditioner |
| Function | Cooling |
| Cooling Capacity | 48000 BTU/Hr |
| 14068 Watts | |
| 4 Ton | |
| Compressor | Twin Rotary (Variable Speed) |
| Refrigerant | R-410a |
| Apply for Kisti | Exchange Now |
| Basic Features | |
| Function | Cooling |
| BTU/hr | 48000 |
| Rated Voltage | 380V-420V ~ 50Hz |
| Rated Input Power (W) | 4450 |
| Rated Current (A) | 20 |
| Cooling Capacity (W) | 14068 |
| EER | 3.16 |
| Cooling Features | |
| Compressor Type | Twin Rotary (Variable Speed) |
| Refrigerant Type | R-410a |
| Refrigerant Amount (Kg) | 2.8 |
| Operating Range (Ambient Temperature) | 18˚C to 43˚C |
| Condenser Type | Copper Tube Condenser |
| Indoor Fin Type | Slit Fin |
| Outdoor Fin Type | Slit Fin |
| Maximum Pipe Length | 30m |
| Operations | |
| Turbo Mode (Faster Cooling) | Yes |
| Turbo Mode (Maximum Cooling) | No |
| Eco Mode | Yes |
| Auto Operation | Yes |
| Dry Mode | Yes |
| Fan Mode | Yes |
| Speed Setting | Yes (Auto, High, Medium, Low) |
| Auto Restart | Yes |
| Comfort Cooling | Yes |
| Timer | Yes |
| Sleep | Yes |
| Remote & Air Deflection | |
| Display Type | LCD |
| Display Back Light | Yes |
| Operation/Control | Via IR (Infrared Ray) |
| Child Lock | No |
| Temperature Unit Change | Yes (Degree Celsius to Fahrenheit) |
| Auto UP-Down Swing | Yes |
| Auto Left-Right Swing | No |
| Dimensions & Weights | |
| Indoor Dimensions (mm) [L×W×H] | Unit- 840 × 840 × 310 |
| Packing- 890 x 890 x 345 | |
| Outdoor Dimensions (mm) [L×W×H] | Unit- 917 x 330 x 1260 |
| Packing- 1030 x 400 x 1290 | |
| Net Weight (Indoor) (Kg) | 35.00 ±1 |
| Gross Weight (Indoor) (Kg) | 40.00 ±1 |
| Net Weight (Outdoor) (Kg) | 96±1 |
| Gross Weight (Outdoor) (Kg) | 110±1 |
| Net Weight (Indoor Front Panel) (Kg) | 5.3±0.25 |
| Gross Weight (Indoor Front Panel) (Kg) | 9.11±0.25 |
| Front panel Unit Dimension (mm) [LxWxH] | 950 x 950 x 45 |
| Guarantee Information | |
|
Product Replacement Guarantee: 1 Year
(Note: if there are manufacturing faults in heat exchanger & compressor)
|
|
| Warranty Information | |
| For Commercial Usage | Compressor Warranty: 5 Years |
| Spare Parts Support: 2 Years | |
| After Sales Service: 1 Year (Free) | |
| Terms & Conditions | |
|
1. This warranty does not cover the following cases -
i) The warranty will be invalid if the product is misused, neglected, rented on a commercial basis. The warranty also will be invalid if repaired, replaced modified by an unauthorized service personnel.
ii) If the product serial number/barcode is removed, altered or duplicated, the warranty will be invalid.
2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.
3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
4. After sales free service will be applicable only at authorized service points.
|
|
| User Manual | |
| Cassette Type English User Manual |  |
| Cassette Type Bangla User Manual | |
|
The Above User Manuals Discuss About The Below Contents-
Available Models, Safety Precautions, Name of Each Part, Use Method of Remote Controller, How To Get The Best Efficiency, Maintenance, Malfunction Check, Error Code Analysis, Installation Place, Installing The Indoor Unit, Installing The Outdoor Unit, Installing The Electric Wire, Installing Panel And Trial Operation and etc…
Note: In order to operate and use this product correctly and safely, this instruction manual should be read carefully before operation. Keep it in a safe place after reading, for future reference.
|
|
